Jinko BFL 715W Tiger Neo N-Type TOPCon Solar Panel
Brand: Jinko
● In stock — ready to deliver
715W High Power Output with 22.98% module efficiency for commercial and utility-scale solar systems
N-Type TOPCon Bifacial Technology for efficient solar energy generation from both sides
41.02V Operating Voltage and 17.43A current at maximum power for high-output performance
1500V DC Maximum System Voltage for large-scale solar installation compatibility
Durable Dual-Glass Design with IP68-rated junction box and 5 years warranty
- Official manufacturer warranty on this product
- Delivery available across Bangladesh
- Installation & after-sale support available
Product details
Jinko 715W N-Type Solar Panel Price in Bbangladesh
The Jinko BFL 715W Tiger Neo N-Type TOPCon Solar Panel is a high-performance solar solution designed for commercial, industrial, and large-scale solar power systems. Featuring advanced N-Type TOPCon technology, this panel delivers high power output and efficient solar energy generation. Its bifacial design can capture sunlight from both sides, helping improve overall energy production under suitable installation conditions. Buy Jinko 715W Solar Panel in Bangladesh from Cyber Energy BD for a reliable solar solution for your energy needs.
Jinko BFL 715W Tiger Neo Solar Panel Full Specifications
Specification | Value |
|---|---|
Maximum Power (Pmax) | 715 W |
Module Efficiency | 22.98% |
Power Tolerance | 0~+3% |
Voltage at Pmax (Vmpp) | 41.02 V |
Current at Pmax (Impp) | 17.43 A |
Open Circuit Voltage (Voc) | 49.20 V |
Short Circuit Current (Isc) | 18.57 A |
Maximum System Voltage | 1500 V DC (IEC) |
Operating Temperature Range | -40°C to +85°C |
Temperature Coefficient of Pmax | -0.29%/°C |
Number of Cells | 156 (2 x 78) N-type TOPCon |
Module Dimensions (L x W x T) | 2384 mm x 1134 mm x 30 mm |
Weight | 34.5 kg |
Front Glass Thickness | 2.0 mm, Heat Strengthened Glass |
Rear Glass Thickness | 2.0 mm, Heat Strengthened Glass |
Frame Material | Anodized Aluminium Alloy |
Junction Box | IP68 Rated, 3 bypass diodes |
Connector | MC4 Compatible |
Cables | 4.0 mm² (0.006 in²) , 400 mm (15.75 in) length (standard) |
